The S(B)H-M Amorphous Alloy Cored Power Transformer leverages a state-of-the-art amorphous alloy core to deliver exceptional energy savings and environmental performance. By dramatically reducing no-load losses and current draw, it cuts operational expenses and aligns with modern green-energy policies.
Designed for low-load-factor scenarios—such as rural distribution networks—this “green material” transformer also minimizes noise and harmful emissions. Its robust construction and advanced core technology ensure long-term reliability, making it an ideal solution for sustainable power distribution.
| Transformer model | Lable of connecting group | No-Load loss (W) |
Load loss (W) |
No-Load current (%) |
Short circuit impedance (%) |
|||
| Rated capacity (KVA) |
Voltage combination and tapping range (kV) | |||||||
| High-Voltage (kV) | High-Voltage tapping range (%) |
Low Voltage (KV) |
||||||
| 30 | 6 6.6 10 10.5 11 |
±5 ±2×2.5 |
0.4 | Dyn11 | 33 | 600 | 1.7 | 4 |
| 50 | 43 | 870 | 1.3 | |||||
| 80 | 50 | 1040 | 1.2 | |||||
| 100 | 60.0 | 1250 | 1.1 | |||||
| 125 | 75.0 | 1500 | 1 | |||||
| 160 | 85 | 1800 | 0.9 | |||||
| 200 | 100 | 2200 | 0.7 | |||||
| 250 | 120 | 2600 | 0.7 | |||||
| 315 | 140 | 3050 | 0.7 | |||||
| 400 | 170.0 | 3650 | 0.5 | |||||
| 500 | 200.0 | 4300 | 0.5 | |||||
| 630 | 240 | 5150 | 0.5 | |||||
| 630 | 320 | 6200 | 0.3 | 5 | ||||
| 800 | 380 | 7500 | 0.3 | |||||
| 1000 | 450 | 10300 | 0.3 | |||||
| 1250 | 530 | 12000 | 0.2 | |||||
| 1600 | 630 | 14500 | 0.2 | |||||
| 2000 | 750 | 17400 | 0.2 | 5 | ||||
| 2500 | 900 | 20200 | 0.2 | |||||
