The SC(B)H15 Amorphous Metal Dry-type Transformer uses oil-free, epoxy-encapsulated windings built around a low-loss amorphous alloy core. Its compact, flame-retardant design eliminates fire and environmental risks, making it ideal for indoor installations in urban high-rise buildings, commercial centers, and critical infrastructure.
Featuring moisture-resistant materials and a crack-proof structure, this transformer delivers stable, maintenance-free operation under demanding conditions. Its low no-load losses and high efficiency help reduce operating costs, while strict fire-safety compliance ensures peace of mind in locations with rigorous safety standards.
| Transformer model | Lable of connecting group | No-Load loss (W) |
Load loss (W) |
No-Load current (%) |
lmpedance Voltage (%) |
|||
| Rated capacity (KVA) |
Voltage combination and tapping range (kV) | |||||||
| High-Voltage (kV) | High-Voltage tapping range (%) |
Low Voltage (KV) |
||||||
| 30 | 6 6.6 10 10.5 11 |
±5 ±2×2.5 |
0.4 | Dyn11 | 70 | 710 | 1.6 | 4 |
| 50 | 90 | 1000 | 1.4 | |||||
| 80 | 120 | 1380 | 1.3 | |||||
| 100 | 130 | 1570 | 1.2 | |||||
| 125 | 150 | 1850 | 1.1 | |||||
| 160 | 170 | 2130 | 1.1 | |||||
| 200 | 200 | 2530 | 1.0 | |||||
| 250 | 230 | 2760 | 1.0 | |||||
| 315 | 280 | 3470 | 0.9 | 6 | ||||
| 400 | 310 | 3990 | 0.8 | |||||
| 500 | 360 | 4880 | 0.8 | |||||
| 630 | 420 | 5880 | 0.7 | |||||
| 630 | 410 | 5960 | 0.7 | |||||
| 800 | 480 | 5960 | 0.7 | |||||
| 1000 | 550 | 6130 | 0.6 | |||||
| 1250 | 650 | 9690 | 0.6 | |||||
| 1600 | 760 | 11730 | 0.6 | |||||
| 2000 | 1000 | 14450 | 0.5 | |||||
| 2500 | 1200 | 17170 | 0.5 | |||||
| 1600 | 760 | 12960 | 0.6 | 8 | ||||
| 2000 | 1000 | 15960 | 0.5 | |||||
| 2500 | 1200 | 18890 | 0.5 | |||||
This product possesses such advantages as low no-load loss, no oil, flame retardant and self-extinguishing properties, moisture resistance, crack resistance, and maintenance-free operation. It can be used to replace conventional dry-type transformers currently applied in many settings. These transformers are ideal for use in high-rise buildings, commercial centers, subways, airports, train stations, enterprises, and power plants. They are especially suitable for locations with strict fire safety requirements, including flame-retardant and explosion-proof standards.
