12KV Integrated Insulator 630～1250A

High Insulation Performance:Withstands 38kV power frequency voltage and 75kV lightning impulse voltage, ensuring safety of electrical equipment.
Epoxy Resin Material:Provides excellent electrical insulation and durability.
Integrated Design:Enhances mechanical strength and simplifies installation.
Suitable for Various Equipment:Ideal for applications like Ring Main Units and Gas-insulated Switchgear.
IP67 Protection Level:Effectively prevents dust and moisture, making it suitable for harsh environments.

Get a Quote

Manual Download

Describe Display

The 12KV Integrated Insulator, made from epoxy resin, is designed for 12kV power systems and is suitable for applications such as Ring Main Units and Gas-insulated Switchgear. It features excellent insulation performance, withstanding power frequency voltage of 38kV and lightning impulse voltage of 75kV to ensure stable operation in high-voltage environments. The integrated design offers enhanced mechanical strength and easy installation, catering to various installation requirements.

With an IP67 protection level, it effectively prevents dust and moisture from entering, making it suitable for demanding environmental conditions.

Product parameters

Type	12KV Series
Rated Voltage	12kV
Rated Current	630～1250A
Power Frequency Withstand Voltage	38kV
Lightning Impulse Withstand Voltage	75kV
Material	Epoxy Resin
Applicable Equipment	Ring Main Unit, Gas-insulated Switchgear
Product Features	Integrated design, High insulation performance
Protection Level	IP67
