35KV Integrated Insulator

One-Piece Molding Design:Enhances mechanical strength and high voltage resistance.
High Voltage Resistance:Withstands 95kV power frequency voltage and 185kV lightning impulse voltage, ensuring the safety of power equipment.
Wide Application:Suitable for high voltage switchgear, isolators, and other equipment.
IP67 Protection Level:Effectively prevents water and dust ingress, suitable for use in harsh environments.
High Mechanical Strength:Ensures durability and stability for long-term use.

Get a Quote

Manual Download

Describe Display

The 35KV Integrated Insulator, made from epoxy resin, is designed for 35kV power systems, particularly suitable for high voltage switchgear and isolators. Its one-piece molding design provides high mechanical strength and high voltage resistance, withstanding 95kV power frequency voltage and 185kV lightning impulse voltage, ensuring safe operation in high-voltage environments. The product features an IP67 protection level, effectively preventing dust and moisture ingress, making it suitable for various harsh environmental conditions and ensuring long-term reliability.

Product parameters

Type	35KV Series
Rated Voltage	35kV
Rated Current	2500A
Power Frequency Withstand Voltage	95kV
Lightning Impulse Withstand Voltage	185kV
Material	Epoxy Resin
Applicable Equipment	High Voltage Switchgear, Isolator
Product Features	One-piece molding, High voltage resistance
Protection Level	IP67
