The JDZXJ1-10RC Voltage Transformer is designed for indoor use in single-phase or three-phase AC circuits. It is widely used for measuring voltage, electric energy, and providing protective relaying in power systems operating at 50Hz or 60Hz, with a rated voltage of 11kV. The transformer adopts a fully enclosed epoxy resin casting structure that enhances insulation strength and environmental protection.
Featuring low magnetic flux density and a large creepage distance on external insulation surfaces, this product delivers high reliability and excellent resistance to dirt and moisture. Its maintenance-free design makes it ideal for long-term, stable performance in medium-voltage indoor applications.
| Type | Rated primary voltage (kV) |
Rated secondary voltage (kV) |
Accuracy classes combination | Rated output (VA) |
Thermal limiting current (VA) |
Rated insulation level (kV) |
| JDZXJ1-12RC |
3/
|
0.1/√3
|
0.2 | 25 | 300 |
3.6/10/40
|
| 0.5 | 50 | |||||
| 1 | 80 | |||||
|
0.1/√3/0.1/3
|
0.2/6P(3P) | 15/100 | 500 | |||
| 0.5/6P(3P) | 30/100 |
Remarks: Upon request we are glad to offer transformers according to other standards or with non-standard technical specs.
