The JSZV2-10RMC Voltage Transformer features an epoxy resin casting and fully enclosed construction, designed for enhanced insulation and long-term durability. The outer surface is covered with a metal shell, providing additional safety and shielding. It is compatible with IEC elbow connectors (EN50181 bushing), making it suitable for modern switchgear integration in three-phase power systems.
This voltage transformer is widely used for measuring current, electric energy, and protective relaying in systems operating at 50Hz or 60Hz, with a maximum equipment voltage of 12kV. Its reliable structure and safety-enhanced design make it ideal for indoor medium-voltage applications requiring compactness, accuracy, and robust protection.
| Rated primary voltage (kV) |
Rated secondary voltage (kV) |
Accuracy classes combination | Rated output (VA) |
Thermal limiting current (VA) |
Rated insulation level (kV) |
| 10 11 |
0.1 0.11 |
0.2 | 25 | 2×600 | 12/28/75 |
| 0.5 | 50 | ||||
| 1 | 100 | ||||
| 0.1/0.1 0.11/0.11 |
0.2/0.2 | 15/15 | 2×300/300 | ||
| 0.2/0.5 | 30/25 | ||||
| 0.1/0.22 0.11/0.22 |
0.2/6P(3P) | 20/600 | 2×600 | ||
| 0.5/6P(3P) | 30/600 |
Remarks: Upon request we are glad to offer transformers according to other standards or with non-standard technical specs.
