The LXSC-10 Zero-Sequence Current Transformer features a newly developed high-permeability core that ensures high measurement accuracy. Its secondary winding is fully enclosed within vacuum-cast, flame-retardant plastic housing, providing robust insulation and durability. Designed for easy installation, the primary cable passes directly through the transformer, making it ideal for electrical systems with equipment voltages up to 0.72kV.
This current transformer is widely applied for current metering, signal collection, and relay protection in power cables. It meets international standards IEC 61869-1:2007, IEC 61869-2:2012, and IEC 60044-1, ensuring reliable performance and safety in demanding environments up to 2000 meters altitude.
| Model | LXSZC-35 | ||
| Rated transformation ratio (A) |
COSΦ=0.8 Accuracy class and rated burden (VA) |
||
| 10P5 | 10P10 | 10P20 | |
| 20/5 | 2.5 | 2.5 | 2.5 |
| 30/5 | |||
| 40/5 | |||
| … | |||
| 100/5 | |||
