The NLS-10/3 10KV Cold Shrink Single-Core Outdoor Terminals are designed for 10KV power systems, providing excellent voltage withstand performance and high reliability. The rated voltage of this product is 10KV, with an AC withstand voltage of 39KV, ensuring safe operation. The product passes the partial discharge test with a discharge of less than 10pC at 30KV, further enhancing its stability. It also successfully passes the 15-minute DC withstand voltage test at 35KV, ensuring long-term safe operation.
This product utilizes cross-linked cable heat-shrink technology to ensure excellent sealing and waterproofing. The dual grounding process (separating steel armor and copper screen ground) makes cable pre-testing easier and more efficient. For oil-impregnated cables, the termination and intermediate cable branches are equipped with oil-sealing finger sleeves, enhancing the product’s safety and reliability for long-term stable operation in power systems.
| Type | NLS-10/3 |
| Rated Voltage | 10kV |
| Power Frequency Withstand Voltage | 10kV |
| 5min Power Frequency Withstand Voltage | 39kV (No Flashover or Breakdown) |
| Partial Discharge Test | <10pC at 30kV |
| 15min DC Withstand Voltage | 35kV (No Flashover or Breakdown) |
| Tensile Strength | >14 |
| Impulse Withstand Voltage Test | 95kV ±10% (No Flashover or Breakdown) |
| Type | Applicable Cable Cross-Section(mm²) |
| NLS-10/1.1 | 25～50 |
| NLS-10/1.2 | 70~120 |
| NLS-10/1.3 | 150~240 |
| NLS-10/1.4 | 300~400 |
