CG 12kV Series Epoxy Resin Sensors
  • Rated Voltage:12KV
  • Material:Epoxy resin
CG 40.5kV Series Sensors
  • Rated Voltage:40.5kV
  • Material:Epoxy resin
WB1-35KV/85 Elbow Plate
  • Rated Voltage:35kV
  • Dimensions:85mm Bending Length
  • Material:Copper or Aluminum Alloy
  • Surface Treatment:Tin-plated or Silver-plated
  • Operating Temperature:-40℃ ～ +105℃
ZJ Series 12kV Post Insulators
  • Rated Voltage:12kV
  • Material:Epoxy resin
WB2-35KV/184 Elbow Plate
  • Rated Voltage:35kV
  • Dimensions:184mm Bending Length
  • Material:Copper or Aluminum Alloy
  • Surface Treatment:Tin-plated or Silver-plated
  • Operating Temperature:-40℃ ～ +105℃
WB-35KV ABB Elbow Plate
  • Rated Voltage:35kV
  • Dimensions:Customized as per ABB Standard
  • Material:Copper or Aluminum Alloy
  • Surface Treatment:Tin-plated or Silver-plated
  • Operating Temperature:-40℃ ～ +105℃
WB 40.5kV Series Elbow Plates
  • Rated Voltage:40.5kv
  • Maximum system voltage:45kv
Characteristics of Insulation Component
Rated Voltage
2kV~40.5kV
Material
Vacuum Cast Epoxy Resin
Power Frequency Withstand Voltage
42kV/1min (12kV class)
Mechanical Strength
≥800MPa
Lightning Impulse Withstand Voltage
75kV (Apex)
Certification
IEC 62271-200, UL 508
Materials
6 global material development partners
Detection
100% internal dielectric and thermal performance testing
Compliance
Designed to meet IEC/ANSI standards
Traceability
Complete batch traceability and leading technical support
Why Choose Us
Strong weathering resistance
adapt to extreme environments such as coastal, high pollution, high temperature and high humidity.
High reliability
Reduces the risk of grid failures and reduces maintenance costs.
International Standard Adaptation
Meet the requirements of power equipment in the European, Middle East and Southeast Asian markets.
FAQ
What types of insulation components do you offer?
We offer epoxy resin insulators, embedded poles, bushings, and insulation parts designed for medium and high voltage switchgear and transformers.
What voltage range do your insulation components support?
Our insulation products are suitable for systems rated from 3.6kV up to 40.5kV, depending on the application.
Our insulation products are suitable for systems rated from 3.6kV up to 40.5kV, depending on the application.
Yes, all our insulation components meet IEC 60243 and IEC 62271 standards for electrical strength and mechanical integrity.
Can I request customized insulator designs?
Yes, we can customize dimensions, mounting options, and material formulations based on your technical drawings or specifications.
